Parameters 309
High limit If 75.14 Sleep signal source 1 is greater than or equal to
75.16 Sleep level and the condition is true longer than time
75.08 Fluid level i-time, the pump will shut down.
The Sleep function is active until 75.14 Sleep signal
source 1 increases to a level less than or equal to 75.18
Wakeup level.
See section Sleep and wake up function on page 35.
1
75.13 Sleep signal source
function
Selects a mathematical function between the feedback
sources selected by parameters 75.14 Sleep signal source
1 and 75.15 Sleep signal source 2.
Source 1
Source1 See parameter 75.14.0
Source2 See parameter 75.15.1
Source1 + Source2 Sum of sources 1 and 2. 2
Source1 - Source2 Source 2 subtracted from source 1. 3
Source1 x Source2 Source 1 multiplied by source 2. 4
Source1 / Source2 Source 1 divided by source 2. 5
75.14 Sleep signal source 1 Defines the source 1 signal monitored for activation of
sleep function.
Zero
Zero Zero 0
AI1 scaled 12.12 AI1 scaled value (see page 141)1
AI2 scaled 12.22 AI2 scaled value (see page 143)2
FBA1 ref Fieldbus adapter A reference1 3
FBA2 ref Fieldbus adapter A reference2 4
Rod speed Actual rod speed 5
Other Source selection (see Terms and abbreviations on page
101)
-
75.15 Sleep signal source 2 Defines the source 2 signal monitored for activation of
sleep function.
Zero
Zero Zero 0
AI1 scaled 12.12 AI1 scaled value (see page 141). 1
AI2 scaled 12.22 AI2 scaled value (see page 143). 2
FBA1 ref Fieldbus adapter A reference1 3
FBA2 ref Fieldbus adapter A reference2 4
Rod speed Actual rod speed 5
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
75.16 Sleep level Defines the set point for activation of sleep function. The
set point percentage of range selected by analog input
source in parameter 75.14 Sleep signal source 1 or
75.15
Sleep signal source 2.
See section Sleep and wake up function on page 35.
Note: The Wakeup level has higher priority than the Sleep
level.
0.00
SourceUnit
0.00...100000000.00
SourceUnit
Sleep level. 100 = 1
SourceUnit
No. Name/Value Description Def/
FbEq16
