Parameters 283
Transparent Scaling: 1 = 1. Range: -32768 … 32767. 1
General Scaling: 1 = 100. Range: -327.68 … 327.67. 2
Torque The scaling is defined by parameter 46.03 Torque scaling.
Range: -1600.0 … 1600.0.
3
Speed The scaling is defined by parameter 46.01 Speed scaling.
Range: -30000.00 … 30000.00.
4
Frequency The scaling is defined by parameter 46.02 Frequency
scaling. Range: -500.00 … 500.00.
5
47.32 Data storage 2 real32
type
Defines the 16-bit scaling of parameter 47.02 Data storage
2 real32.
See parameter 47.31 Data storage 1 real32 type.
Unscaled
47.33 Data storage 3 real32
type
Defines the 16-bit scaling of parameter 47.03 Data storage
3 real32.
See parameter 47.31 Data storage 1 real32 type.
Unscaled
47.34 Data storage 4 real32
type
Defines the 16-bit scaling of parameter 47.04 Data storage
4 real32.
See parameter 47.31 Data storage 1 real32 type.
Unscaled
47.35 Data storage 5 real32
type
Defines the 16-bit scaling of parameter 47.05 Data storage
5 real32.
See parameter 47.31 Data storage 1 real32 type.
Unscaled
47.36 Data storage 6 real32
type
Defines the 16-bit scaling of parameter 47.06 Data storage
6 real32.
See parameter 47.31 Data storage 1 real32 type.
Unscaled
47.37 Data storage 7 real32
type
Defines the 16-bit scaling of parameter 47.07 Data storage
7 real32.
See parameter 47.31 Data storage 1 real32 type.
Unscaled
47.38 Data storage 8 real32
type
Defines the 16-bit scaling of parameter 47.08 Data storage
8 real32.
See parameter 47.31 Data storage 1 real32 type.
Unscaled
49
49 Panel port
communication
Communication settings for the control panel port on the
drive.
49.01 Node ID number Defines the node ID of the drive. All devices connected to
the network must have a unique node ID.
Note: For networked drives, it is advisable to reserve ID 1
for spare/replacement drives.
1
1…32 Node ID. 1 = 1
49.03 Baud rate Defines the transfer rate of the link. 230.4 kbps
38.4 kbps 38.4 kbit/s. 1
57.6 kbps 57.6 kbit/s. 2
86.4 kbps 86.4 kbit/s. 3
115.2 kbps 115.2 kbit/s. 4
230.4 kbps 230.4 kbit/s. 5
49.04 Communication loss
time
Sets a timeout for control panel (or PC tool)
communication. If a communication break lasts longer
than the timeout, the action specified by parameter 49.05
Communication loss action is taken.
10.0 s
0.3…3000.0 s Panel/PC tool communication timeout. 10 = 1 s
No. Name/Value Description Def/
FbEq16
