Fieldbus control through the embedded fieldbus interface (EFB) 457
Coils (0xxxx reference set)
Coils are 1-bit read/write values. Control Word bits are exposed with this data type.
The table below summarizes the Modbus coils (0xxxx reference set).
Reference ABB drives profile Transparent profile
00001 OFF1_CONTROL Control Word bit 0
00002 OFF2_CONTROL Control Word bit 1
00003 OFF3_CONTROL Control Word bit 2
00004 INHIBIT_OPERATION Control Word bit 3
00005 RAMP_OUT_ZERO Control Word bit 4
00006 RAMP_HOLD Control Word bit 5
00007 RAMP_IN_ZERO Control Word bit 6
00008 RESET Control Word bit 7
00009 JOGGING_1 Control Word bit 8
00010 JOGGING_2 Control Word bit 9
00011 REMOTE_CMD Control Word bit 10
00012 EXT_CTRL_LOC Control Word bit 11
00013 User-defined (0) Control Word bit 12
00014 User-defined (1) Control Word bit 13
00015 User-defined (2) Control Word bit 14
00016 User-defined (3) Control Word bit 15
00017 Reserved Control Word bit 16
00018 Reserved Control Word bit 17
00019 Reserved Control Word bit 18
00020 Reserved Control Word bit 19
00021 Reserved Control Word bit 20
00022 Reserved Control Word bit 21
00023 Reserved Control Word bit 22
00024 Reserved Control Word bit 23
00025 Reserved Control Word bit 24
00026 Reserved Control Word bit 25
00027 Reserved Control Word bit 26
00028 Reserved Control Word bit 27
00029 Reserved Control Word bit 28
00030 Reserved Control Word bit 29
00031 Reserved Control Word bit 30
00032 Reserved Control Word bit 31
00033 Reserved 10.99 RO/DIO control word, bit 0
00034 Reserved 10.99 RO/DIO control word, bit 1
