316 Parameters
AI1 scaled 12.12 AI1 scaled value (see page 141). 1
AI2 scaled 12.22 AI2 scaled value (see page 143). 2
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
79.05 PT100 exitation
source
Feeding current for 1…3 PT100 sensors. Zero
Zero Zero. 0
Internal selection See par 79.06 PT100 internal selection.1
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
79.06 PT100 internal
selection
User defined feeding current. 9.10 mA
0.00...20.00 mA PT100 internal selection. 100 = 1 mA
79.07 Number of PT100
sensors in series
Number of connected PT100 sensors. 1
1...3 Number of PT100 sensors connected in series. 1 = 1
79.08 Warning temperature
limit
Temperature limit for displaying warning message. 0.00 °C
0.00...200.00 °C Warning temperature limit. 10 = 1 °C
79.09 Fault temperature
limit
Temperature limit, that triggers a fault. 0.00 °C
0.00...200.00 °C Fault temperature limit. 10 = 1 °C
80 Pump backspin
control
Basic functions of applications.
80.01 Backspin enable Enables the Backspin function. See section Pump
backspin control on page 47.
Disable
Disable Disable backspin function. 0
Enable Enable backspin function. 1
Other Source selection (see Terms and abbreviations on
page 101).
-
80.02 Backspin ref limit Defines the reference speed/frequency limit for the
Backspin function. See section Pump backspin control on
page 47.
WARNING! If Backspin ref limit is set to 0, the
Pump backspin control procedure is ineffective.
0.00 Prpm,
rpm or Hz
-500.00...0.00 Reference limit 10 = 1 Prpm,
rpm or Hz
80.03 Backspin acc time Defines the acceleration time for the Backspin function:
from zero speed to 80.02 Backspin ref limit.
0.000 s
0.000...10000.000 s Acceleration time 10 = 1 s
80.04 Backspin stop torque Defines a torque limit for the Backspin function. See
section Pump backspin control on page 47.
When the actual torque is below the limit, Backspin
function is complete and it gives coast to stop command to
the drive.
Note: This setting eliminates excessive shut down times.
0.00 N•m or
lbft
No. Name/Value Description Def/
FbEq16

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
