ABB ACS880 PCP User Manual

Additional parameter data 365
04.44 Event word 1 bit 1 aux
code
Data 0000 0000h … FFFF FFFFh - 1 = 1
…… … … …
04.71 Event word 1 bit 15 code Data 0000h…FFFFh - 1 = 1
04.72 Event word 1 bit 15 aux
code
Data 0000 0000h … FFFF FFFFh - 1 = 1
04.120 Fault/Warning word
compatibility
List 0…1 - 1 = 1
05 Diagnostics
05.01 On-time counter Real 0…65535 d 1 = 1 d
05.02 Run-time counter Real 0…65535 d 1 = 1 d
05.04 Fan on-time counter Real 0…65535 d 1 = 1 d
05.11 Inverter temperature Real -40.0…160.0 % 10 = 1%
05.22 Diagnostic word 3 PB 0000h…FFFFh - 1 = 1
05.41 Main fan service counter Real 0…150 % 1 = 1%
05.42 Aux. fan service counter Real 0…150 % 1 = 1%
06 Control and status words
06.01 Main control word PB 0000h…FFFFh - 1 = 1
06.02 Application control word PB 0000h…FFFFh - 1 = 1
06.03 FBA A transparent control
word
PB 00000000h…FFFFFFFFh - 1 = 1
06.04 FBA B transparent control
word
PB 00000000h…FFFFFFFFh - 1 = 1
06.05 EFB transparent control
word
PB 00000000h…FFFFFFFFh -
06.11 Main status word PB 0000h…FFFFh - 1 = 1
06.16 Drive status word 1 PB 0000h…FFFFh - 1 = 1
06.17 Drive status word 2 PB 0000h…FFFFh - 1 = 1
06.18 Start inhibit status word PB 0000h…FFFFh - 1 = 1
06.19 Speed control status word PB 0000h…FFFFh - 1 = 1
06.29 MSW bit 10 sel Binary
src
--1 = 1
06.30 MSW bit 11 sel Binary
src
--1 = 1
06.31 MSW bit 12 sel Binary
src
--1 = 1
06.32 MSW bit 13 sel Binary
src
--1 = 1
06.33 MSW bit 14 sel Binary
src
--1 = 1
06.50 User status word 1 PB 0000h...FFFFh - 1 = 1
06.60 User status word 1 bit 0
sel
Binary
src
--1 = 1
06.61 User status word 1 bit 1
sel
Binary
src
--1 = 1
No. Name Type Range Unit FbEq32

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
