Additional parameter data 375
15.76 AO1 actual value Real 0.000…22.000 mA 1000 = 1 mA
15.77 AO1 source Analog
src
--1 = 1
15.78 AO1 force data Real 0.000…22.000 mA 1000 = 1 mA
15.79 AO1 filter time Real 0.000…30.000 s 1000 = 1 s
15.80 AO1 source min Real -32768.0…32767.0 - 10 = 1
15.81 AO1 source max Real -32768.0…32767.0 - 10 = 1
15.82 AO1 out at AO1 src min Real 0.000…22.000 mA 1000 = 1 mA
15.83 AO1 out at AO1 src max Real 0.000…22.000 mA 1000 = 1 mA
AO2 (15.01 Module 2 type = FIO-11 or FA IO-01 )
15.86 AO2 actual value Real 0.000…22.000 mA 1000 = 1 mA
15.87 AO2 source Analog
src
--1 = 1
15.88 AO2 force data Real 0.000…22.000 mA 1000 = 1 mA
15.89 AO2 filter time Real 0.000…30.000 s 1000 = 1 s
15.90 AO2 source min Real -32768.0…32767.0 - 10 = 1
15.91 AO2 source max Real -32768.0…32767.0 - 10 = 1
15.92 AO2 out at AO1 src min Real 0.000…22.000 mA 1000 = 1 mA
15.93 AO2 out at AO1 src max Real 0.000…22.000 mA 1000 = 1 mA
16 I/O extension module 3
16.01 Module 3 type List --1 = 1
16.02 Module 3 location Real 1…254 - 1 = 1
16.03 Module 3 status List 0…2 - 1 = 1
Common parameters for DIOx (16.01 Module 3 type = FIO-01 or FIO-11)
16.05 DIO status PB 00000000h…FFFFFFFFh - 1 = 1
16.06 DIO delayed status PB 00000000h…FFFFFFFFh - 1 = 1
DIO1/DIO2 (16.01 Module 3 type = FIO-01 or FIO-11)
16.08 DIO filter time Real 0.8...100.0 ms 10 = 1 ms
16.09 DIO1 function List 0…1 - 1 = 1
16.11 DIO1 output source Binary
src
--1 = 1
16.12 DIO1 ON delay Real 0.0 … 3000.0 s 10 = 1 s
16.13 DIO1 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
16.14 DIO2 function List 0…1 - 1 = 1
16.16 DIO2 output source Binary
src
--1 = 1
16.17 DIO2 ON delay Real 0.0 … 3000.0 s 10 = 1 s
16.18 DIO2 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
DIO3/DIO4 (16.01 Module 3 type = FIO-01)
16.19 DIO3 function List 0…1 - 1 = 1
16.21 DIO3 output source Binary
src
--1 = 1
No. Name Type Range Unit FbEq32
