Additional parameter data 381
23.20 Acc time jogging Real 0.000 …1800.000 s 1000 = 1 s
23.21 Dec time jogging Real 0.000 …1800.000 s 1000 = 1 s
23.23 Emergency stop time Real 0.000 …1800.000 s 1000 = 1 s
23.24 Speed ramp in zero source Binary
src
--1 = 1
23.26 Ramp out balancing enable Binary
src
--1 = 1
23.27 Ramp out balancing ref Real -30000.00…30000.00 rpm 100 = 1 rpm
23.28 Variable slope enable List 0…1 - 1 = 1
23.29 Variable slope rate Real 2…30000 ms 1 = 1 ms
23.39 Follower speed correction out Real -30000.00...30000.00 rpm 100 = 1 rpm
23.40 Follower speed correction
enable
Binary
src
--1 = 1
23.41 Follower speed correction gain Real 0.00...100.00 % 100 = 1%
24 Speed reference conditioning
24.01 Used speed reference Real -30000.00…30000.00 rpm 100 = 1 rpm
24.02 Used speed feedback Real -30000.00…30000.00 rpm 100 = 1 rpm
24.03 Speed error filtered Real -30000.00…30000.00 rpm 100 = 1 rpm
24.04 Speed error inverted Real -30000.00…30000.00 rpm 100 = 1 rpm
24.11 Speed correction Real -10000.00…10000.00 - 100 = 1
24.12 Speed error filter time Real 0…10000 ms 1 = 1 ms
24.41 Speed error window control
enable
List 0…1 - 1 = 1
24.42 Speed window control mode List 0…1 - 1 = 1
24.43 Speed error window high Real 0.00…3000.00 rpm 100 = 1 rpm
24.44 Speed error window low Real 0.00…3000.00 rpm 100 = 1 rpm
24.46 Speed error step Real -3000.00…3000.00 rpm 100 = 1 rpm
25 Speed control
25.01 Torque reference speed
control
Real -1600.0…1600.0 % 10 = 1%
25.02 Speed proportional gain Real 0.00…250.00 - 100 = 1
25.03 Speed integration time Real 0.00…1000.00 s 100 = 1 s
25.04 Speed derivation time Real 0.000…10000.000 s 1000 = 1 s
25.05 Derivation filter time Real 0…10000 ms 1 = 1 ms
25.06 Acc comp derivation time Real 0.00…1000.00 s 100 = 1 s
25.07 Acc comp filter time Real 0.0…1000.0 ms 10 = 1 ms
25.08 Drooping rate Real 0.00…100.00 % 100 = 1%
25.09 Speed ctrl balancing enable Binary
src
--1 = 1
25.10 Speed ctrl balancing ref Real -300.0…300.0 % 10 = 1%
25.11 Speed control min torque Real -1600.0…0.0 % 10 = 1%
25.12 Speed control max torque Real 0.0…1600.0 % 10 = 1%
25.13 Min torq sp ctrl em stop Real -1600…0 % 10 = 1%
No. Name Type Range Unit FbEq32
