3.3.4 AC plate
A
C
B
D E GF
A Terminal X1
B Terminal X2
C Terminal X3
D Fuse F10
E Fuse F21
F Fuse F22
G Circuit breaker Q2
Part Function
Terminal X1 To connect the precommissioning cables
Terminal X2 To connect the AC cables
Terminal X3 To connect the AC cables
Fuse F10 To prevent the electrical circuit from an overload
Fuse F21 To prevent the electrical circuit from an overload
Fuse F22 To prevent the electrical circuit from an overload
Circuit breaker Q2 To stop or start the electrical current
Description
24 HVC 200/300/360-EN | 002
