ABB HVC 200 User Manual

Parameter Specification
Conductor Bunch stranded in bare copper, fine wired,
according to VDE 0295 Cl.5/IEC Cl.5
Insulation PVC that is serviceable for outdoor use, UV-
protected, and oil resistant
Nominal voltage Uo/U 480 Vac
Minimum test voltage 4 kV
Ambient temperature range -40 °C to +80 °C (-40 °F to +176 °F)
Strip length 11 mm (0.4 in)
12.13.7 PE cables
Parameter Specification
Type Unshielded
Number of cores 1
Core identification green-yellow
Diameter 10-14mm (0.4-0.6 in)
Cross sec-
tion
Between earth and
the power cabinet
120 mm² (4/0 AWG)
Between the power
cabinet and oher de-
vices
35 mm² (2 AWG)
Conductor Fine strand copper wire according to VDE 0295
Cl. 5/ IEC 60228 Cl. 5
Insulation PVC that is serviceable for outdoor use, UV-
protected, and oil resistant
Nominal voltage Uo/U 480 Vac
Minimum test voltage 4 kV
Ambient temperature range -40 °C to +80 °C (-40 °F to +176 °F)
Strip length Acc. to the used wire end ring
12.13.8 Interlock cables
Parameter Specification
Type Shielded (tinned copper braid)
Number of pairs 1 x 2
Core identification Acc. to DIN 47100
Cross section 0.75-2.5 mm² (20-14 AWG)
Diameter 5-10mm (0.19-0.39 in)
Conductor Fine strand copper wire
Insulation PVC that is serviceable for outdoor use, UV-
protected, and oil resistant
Characteristic impedance 120 Ω ± 10%
Test voltage 1.5 kV
Technical data
HVC 200/300/360-EN | 002 85
