Use
Torch Service Center - TSC 2013 3HDA000057A8519-001 1-5
Assembly instructions
1 Torch Service Center - TSC 2013
1.1 Use
1.1.1 Designated use
The TSC 2013 is a compact, multi-functional torch service station and is used exclusively in auto-
matic robot gas-shielded arc welding for torch cleaning, wire cutting and TCP gauging.
Intended place of installation:
In the working range of an industrial robot.
Service life:
20 years
1.1.2 Non-designated use
Any usage of the TC 3013 deviating from designated use is regarded as non-designated use.
The TSC 2013 must only be used in accordance with the operating conditions and performance
data stipulated in the installation instructions.
Other or more extensive use or unauthorised reconstruction or modification of the TC 2013 is
deemed as not being in accordance with designated use.
TSC means: T= Torch, S= Service, C= Center
Designated use also includes following all advice in
the installation instructions and complying with the
maintenance specifications.
Product liability and warranty are invalidated by unau-
thorised interventions and non-designated use.
