Assembly and disassembly
2-12 3HDA000057A8519-001 Torch cleaner TC 2013
Assembly instructions
2.4.3 Installation
2.4.3.1 Electrical installation
It must be ensured in installation of the TC 2013
• that the cables do not rest on sharp edges,
• that the cables as far as possible are laid in a cable duct,
• the of risk of tripping is minimised.
Before electrical installation work is performed on the TC 2013
• disconnect the power supply to the control part,
• turn off the main on/off switch,
• safely turn off the air supply to the TC 2013,
• keep the system pressureless.
2.4.3.2 Pneumatic installation
The connection of compressed air takes place at the push-in fitting or the screw-in thread G 1/8"
at the filter regulator.
Electrical installation must only be performed by qual-
ified personnel!
The attached electrical circuit diagram must be
observed in installation! (see Chapter 2.10 Electrical
circuit diagram)
The grounding actions performed must be checked by
measurements and recorded.
Installation of the pneumatics must only be performed
by qualified personnel!
The TC 2013 is to connected so that the valves are not
electrically live in an emergency stop.
The attached pneumatic diagram must be observed in
installation! (see Chapter 2.9 Pneumatic plan)
