Commissioning
2-16 3HDA000057A8519-001 Torch cleaner TC 2013
Assembly instructions
2.5 Commissioning
2.5.1 Instructions for commissioning
Before operating for the first time it should be checked that
• all components are correctly assembled and attached,
• all electrical connections are correctly made,
• all pneumatic connections are correctly dimensioned and connected,
• all supply lines have been installed,
• the functioning of all safety devices has been ensured,
• there is sufficient oil in the oiler,
• there is sufficient release agent in the release agent tank,
2.5.2 Function test
A function test in manual mode is to be performed during commissioning of the TC 2013.
Ensure in testing or programming work that the welding torch is correctly introduced into the TC
2013 by the robot.
Ensure in testing the TC 2013 in connection with a welding torch that no weld spatter, metal chips
or debris from a broken milling cutter of spray fluid enter the eyes.
Danger from incorrect connections/settings and non-
functioning/missing safety devices
Tests may only be performed in manual mode and only
by qualified personnel.
Wear suitable protective goggles!
Do not place fingers in the rotating milling cutter or in
the clamping device (V-block)!
Danger due to unexpected starting of the milling cut-
ter!
