Assembly and disassembly
Torch cleaner TC 2013 3HDA000057A8519-001 2-11
Assembly instructions
2.4 Assembly and disassembly
2.4.1 General
The TC 2013 is supplied fully assembled.
Each individual unit is tested after manufacturing and provided with a serial number. The test
results are recorded.
After receipt of the delivery, the TC 2013 is to be examined for any damage in transport and for
completeness on the basis of the delivery note.
2.4.2 Setting up and securing
1. The TC 2013 is to be set up vertically at a suitable place in the robot welding system.
Suitable means:
• within the working range of the robot,
• outside the interference edges of a tool clamping mechanism,
• outside the interference edges of a rotary positioner / turntable
• The basic position of the robot is preferably defined with the arrangement of the TC 2013.
A steel plate or a concrete floor with a quality of at least B 25 is necessary as a base. The base
must be a continuous unit. Setting up over an expansion joint is not permitted.
2. Screwing and pinning of the baseplate of the TC 2013 with the base (4 x M 12 screws).
3. Determination and setting of optimum height and subsequent pegging.
4. Connect grounding cable (threaded drilled hole M8 in the lower area of the stand).
5. Connect compressed air.
6. Connect power supply .
7. Unscrew release agent tank and connect filled position sensor.
Before work is undertaken on the TC 2013 the power
supply to the system is to be disconnected and protec-
tion against switching back on is to be ensured.
All hoses must be pressureless and empty.
There is a danger of the TC 2013 tipping over, and it
should therefore be secured immediately after being
set up.
