Technical data
4-2 3HDA000057A8519-001 TCP gauging (BullsEye
®
)
Assembly instructions
4.2 Technical data
4.2.1 Dimensions
4.2.2 Connection data electrics
Adjusting tip
Protective sleeve
Electrical connection 40mA, at 24VDC
Connection of robot digital sensor input
