Technical data of TC 2013
Torch cleaner TC 2013 3HDA000057A8519-001 2-5
Assembly instructions
2.2.3 Spacer plates
The spacer plate represented in Figure 2-1 is selected into dependence of the used gas nozzle
diameter.
Spacer plates are available in the following strengths:
The gas nozzle diameter has to be transmitted to ABB
Automation GmbH as in Section 2.2.2 "Milling cutter"
described.
Table 2-1 Replacement spacer plates
Gas nozzle
external diameter
[mm]
Strength
[mm]
Ø 16 12.50
Ø 17 11.85
Ø 18 11.20
Ø 19 10.55
Ø 20 9.90
Ø 21 9.25
Ø 22 8.60
Ø 23 7.95
Ø 24 7.30
Ø 25 6.65
Ø 26 6.00
Ø 27 5.35
Ø 28 4.70
Ø 29 4.05
Ø 30 3.40
Ø 31 2.75
Ø 32 2.10
Ø 33 1.45
Ø 34 0.80
Instructions for changing spacer plate and milling cut-
ter you find in Section 2.3.3 "Replacement parts".
