ACUTRONIC fabian User Manual

4 System functions and displays 22
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
Graphics menu
The Graphics menu can be accessed from the Waves button on the Keypad.
The Graphics menu
Displays the current values in big
letters and also shows the pressure
wave.
Use the Waves button to
access the big screen menu.
Figure 4-11: Not filled Waves
The button below Freeze stops the
waves being updated. The key will turn
Green.
The measured parameters in the
Display field continue being updated.
Press the Freeze key again to continue
updating the Waves data.
Figure 4-12: Freeze Waves
