Square wave Output
The U1253B true RMS OLED multimeter’s square wave output
can be used to generate a PWM (pulse width modulation) output
or provide a synchronous clock source (baud rate generator).
You can also use this function to check and calibrate flow- meter
displays, counters, tachometers, oscilloscopes, frequency
converters, frequency transmitters, and other frequency input
devices.
Selecting square wave output frequency
1 Set the rotary switch to . The default pulse width
is 0.8333 ms and default frequency is 600 Hz, as shown
on the primary and secondary displays respectively.
2 Press to switch between duty cycle and pulse width
for the primary display.
3 Press or to scroll through the available frequencies
(there are 29 frequencies to choose from).
Table 3- 1 Available frequencies for square wave output
Frequency (Hz)
0.5, 1, 2, 5, 6, 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 120, 150, 200, 240, 300,
400, 480, 600, 800, 1200, 1600, 2400, 4800
