Agilent Technologies U1253B User Manual

184 U1253B User’s and Service Guide
7 Specifications
AC+DC Specifications
Table 7-4 Accuracy specifications ± (% of reading + number of LSD) for AC+DC voltage
Function Range
[4]
Resolution
Accuracy for AC+DC voltage
[1][2]
30 Hz to 45
Hz
45 Hz to 1
kHz
1 kHz to 5
kHz
5 kHz to 15
kHz
15 kHz to
100 kHz
[3]
Voltage
50.000 mV 0.001 mV 1.5 + 80 0.4 + 60 0.7 + 60 0.8 + 60 3.5 + 220
500.00 mV 0.01 mV 1.5 + 65 0.4 + 30 0.4 + 30 0.8 + 45 3.5 + 125
1000.0 mV 0.1 mV 1.5 + 65 0.4 + 30 0.4 + 30 0.8 + 45 3.5 + 125
5.0000 V 0.0001 V 1.5 + 65 0.4 + 30 0.6 + 30 1.5 + 45 3.5 + 125
50.000 V 0.001 V 1.5 + 65 0.4 + 30 0.4 + 30 1.5 + 45 3.5 + 125
500.00 V 0.01 V 1.5 + 65 0.4 + 30 0.4 + 30 - -
1000.0 V 0.1 V 1.5 + 65 0.4 + 45 0.4 + 45 - -
Notes for AC + DC voltage specifications:
1 Input impedance: Refer to Ta b l e 7 - 1 7 .
2 These specifications are defined for signal input > 5% of range.
3 Additional error to be added for frequency > 15 kHz and signal input < 10% of range: 3 counts of LSD per kHz.
4 2% over-range on all ranges except AC 1000V.
