186 U1253B User’s and Service Guide
7 Specifications
Capacitance Specifications
Table 7-6 Capacitance specifications
Range Resolution Accuracy Display update rate (approx)
10.000 nF 0.001 nF 1% + 8
4 times/second
100.00 nF 0.01 nF
1% + 5
1000.0 nF 0.1 nF
10.000 µF 0.001 µF
100.00 µF 0.01 µF
1000.0 µF 0.1 µF 1 time/second
10.000 mF 0.001 mF 0.1 time/second
100.00 mF 0.01 mF 3% + 10 0.01 time/second
Notes for capacitance specifications:
1 Overload protection: 1000 Vrms for circuits with < 0.3 A short circuit.
2 With film capacitor or better, use Null function to zero out residual.
