6 U1253B User’s and Service Guide
1Getting Started
To adjust the multimeter to a 30° standing position, bend the
tip of the stand so that it is parallel to ground, then pull the
stand outward to its maximum reach.
Figure 1-2 Tilt-stand at 30°
To adjust the multimeter to a hanging position, follow these
steps below or Figure 1- 3 on page 7:
1 Flip the stand upward and over its maximum reach until
it is detached from its hinge.
2 Flip the now detached stand over so that its inner surface
is facing the multimeter as opposed to facing you.
3 Press the stand down into its hinge in an upright
position.
IR-USB cable
To P C ( h o s t)
Tilt-stand at 30
°
