This group of parameters contains binary status information to display which adapters are issuing control
commands.
Owners
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
“Adapter 1”
Adapter 3
Adapter 4
Adapter 5
Not Used
Adapter 2
Adapter 6
Owners
“TB2”
Adapter 1
“Adapter 2”
“Adapter 3”
“Adapter 4”
“Adapter 5”
“Adapter 6”
N/A
TB2
[Sto
p
Owner]
Parameter # 102
[Stop
Owner]
Parameter Type Read Only
This parameter displays which adapters are currently
issuing a valid stop command.
Units Byte Settings 1
0
Controlling
Not Controlling
[Direction Owner]
Parameter # 103
[Direction
Owner]
Parameter Type Read Only
This parameter displays which adapter currently has
exclusive control of direction changes. When commanding
the direction from an adapter, the corresponding bit is set
to “1”.
Important: Only one adapter is allowed to control direction
at any instance.
Units Byte Settings 1
0
Controlling
Not Controlling
