Allen-Bradley 1305 Series User Manual

Human Interface Module
3-7
PROGRAM AND DISPLAY MODES
ACTION
DESCRIPTION
HIM DISPLAY
or
or
or
❏ 1. The Display and Program modes allow access to the parameters for
viewing or programming.
a. From the Status Display, press Enter (or any key). “Choose Mode” will
be shown.
b. Press the Increment (or Decrement) key to show “Program”
(or “Display”).
c. Press Enter.
d. Press the Increment (or Decrement) key until the desired group is
displayed.
e. Press Enter.
f. Press the Increment (or Decrement) key to scroll to the desired
parameter.
Choose Mode
Display
Output Current
0.00 Amps
Choose Group
Metering
Choose Mode
Program
