Allen-Bradley 1305 Series User Manual

Human Interface Module
3-15
CONTROL STATUS MODE
ACTION
DESCRIPTION
HIM DISPLAY
Control Logic
or
or
or
SEL
❏ 1. The Control Status mode is only available with Series A HIM software
version 3.00 and above or Series B HIM software version 1.01 and above.
This mode allows the drive logic mask to be disabled, thus preventing a
Serial Fault when the HIM is removed with drive power applied.
a. From the Status Display, press Enter (or any key). “Choose Mode” will
be shown.
b. Press the Increment (or Decrement) key until “Control Status” is
displayed. Press Enter.
c. Select “Control Logic” using the Increment/Decrement keys. Press
Enter.
d. Press the SEL key, then use the Increment (or Decrement) key to select
“Disabled” (or “Enable”).
e. Press Enter. The logic mask is now disabled (or enabled).
Choose Mode
Display
Choose Mode
Control Status
Control Status
Control Logic
Control Logic
Disabled
