Block Diagram and Specifications
A-2
Table A.1 Specifications
Drive
Bulletin 1305 Drive Rated 200-230 V AC Bulletin 1305 Drives Rated 380-460 V AC
-AA02A -AA03A -AA04A -AA08A -AA12A -BA01A -BA02A -BA03A -BA04A -BA06A -BA09A
OUTPUT RATINGS
Three-Phase Motor Rating
kW (HP)
0.37
(0.5)
0.55
(0.75)
0.75
(1)
1.5
(2)
2.2
(3)
0.37
(0.5)
0.55
(0.75)
0.75
(1)
1.5
(2)
2.2
(3)
4.0
(5)
Output Current (A) ➀➁ 2.3 3.0 4.5 8.0 12.0 ➂ 1.3 1.6 2.3 4.0 6.0 ➃ 9.0 ➄
Output Voltage Adjustable from 0 V to Input Voltage
Output Frequency (Hz) 0.00 to 400.00 Hz Programmable
SCANport Load 250 mA maximum (all adapters combined)
INPUT RATINGS
Input Voltage & Frequency 200/230V Three Phase, 50/60 Hz 380/460V Three Phase, 50/60 Hz
Operational Range (V) 180-265V, 47-63 Hz 340V-500V, 47-63 Hz
Input kVA 0.9 1.3 1.7 3.1 4.6 0.9 1.3 1.7 3.1 4.6 7.0
Power Factor (Displacement) 0.8 (Lagging)
Efficiency (%) 97.5 % (Typical)
Power Dissipation (W) 27 34 46 76 108 21 27 34 52 73 107
In general:
➀ Motor Full Load Amps (FLA) should not exceed the drive output current rating.
➁ If the [PWM Frequency] is set above 4kHz, the output current must be derated per the chart on page 5-20.
When operating the drive in an ambient temperature at or near the maximum operating temperature (50°C), the following derating guidelines are recommended to guard against
overheating depending on application and operating conditions.
➂ Output current value listed for 200V input voltage. At 230V input voltage, output current is 9.6A for 3 phase and 6.8A for single phase.
➃ Output current value listed for 380V input voltage. At 415V input voltage, output current is 5.3A. At 460V input voltage, output current is 4.8A.
➄ Output current value listed for 380V input voltage. At 415V input voltage, output current is 8.4A. At 460V input voltage, output current is 7.6A.
For derating guidelines at ambient temperatures between 40°C and 50°C, consult Allen-Bradley.
