Allen-Bradley 1305 Series User Manual

Serial Communications
B-5
Table B.4 Parameter Grouping/User Settings
Group Parameter Name
Parameter
Number
Display
Units
Drive Units
Scale Factor ➁
Minimum Maximum Factory Setting
User‘s
Setting
Output Current 54 Amps 100 0.00 Two times drive output current ––
Output Voltage 1 Volts 100 0 Maximum Voltage ––
Output Power 23 kW 100 0.00 Two times rated drive output power ––
e
ring
DC Bus Voltage 53 Volts 1 0 410 - 230V Drive
815 - 460V Drive
––
M
et
e
Output Freq 66 Hz 32767 = Max. Freq Max. Frequency Maximum Frequency ––
M
Freq Command 65 Hz 100 0.00 +400.00 0.00
MOP Hz 42 Hz 100 0.00 400.00 ––
Drive Temp 70 Degrees C 1 0 100 ––
Last Fault 4 Numeric 1 0 Max. Fault Number ––
% Output Power 3 % 1 0 200% Drive Rated Power ––
% Output Curr 2 % 1 0 200% of Rated Drive Output Current ––
➀ Refer to Table B.5 on pages B-13, B-14 and B-15 for the numerical equivalent of the text descriptions
➁ Refer to page B-2.
