Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 133
Configure the Module for a SmartGuard Controller Chapter 6
Save and Download Module
Configuration
We recommend that after a module is configured you save your work
If the MS and NS status indicators on the POINT Guard I/O module are not
both solid green after download, ownership has the potential to have been lost.
The ownership is based on the following:
• POINT Guard I/O module number
• POINT Guard I/O safety network number
• SmartGuard slot number
• SmartGuard safety network number
• Path from SmartGuard controller to POINT Guard I/O module
• Configuration signature
If any of the preceding parameters change, the connection between the
SmartGuard controller and the POINT Guard I/O module is lost, and a yellow
yield icon appears in the RSNetWorx for DeviceNet tree. For more information,
see Chapter 8
.
If you have not followed the configuration guidelines in the parameter tables
found in Configure Safety Analog Inputs
on page 123, the error message
“Invalid Configuration Parameter occurred while attempting to configure the
safety device” appears in the Error Log during download.
