146 Rockwell Automation Publication 1734-UM013N-EN-P - September 2017
Chapter 7 Configuring Safety Connections between a GuardLogix Controller and POINT Guard I/O Modules on a DeviceNet Network
To begin the upload and compare process, click Next.
If you click Next without selecting a device to verify, the wizard checks
whether any devices were verified or are ready to be locked in this
execution of the wizard.
If Then the wizard displays
Devices were verified The Review dialog box that lists those devices.
Devices are ready to be safety-
locked
The Lock dialog box that lists those devices.
No devices were verified The Finish dialog box.
No devices are ready to be
safety-locked
The Finish dialog box.
