Page #135 background imageLoading...
Page #135 background image
Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 135
Module Tag Definitions Appendix B
5069-IF8 Module Tags
This section describes the tags associated with the 5069-IF8 module.
Configuration Tags
Table 30 describes the 5069-IF8 module configuration tags.
Table 30 - 5069-IF8 Module - Configuration Tags
Name Size Definition Valid Values
Chxx.Range SINT Channel’s operating range 0 = -10…10V
1 = 0…5V
2 = 0…10V
4 = 0…20 mA
5 = 4…20 mA
Chxx.NotchFilter SINT Notch Filter removes line noise for the channel. 0 = 10 Hz (simultaneous 50/60Hz
rejection)
1 = 50 Hz
2 = 60 Hz
3 = 100 Hz
4 = 200 Hz
5 = 500 Hz
6 = 1,000 Hz
7 = 2,500 Hz
8 = 5,000 Hz
9 = 10,000 Hz
10 = 15,625 Hz
11 = 25,000 Hz
12 = 31,250 Hz
13 = 5 Hz
14 = 62,500 Hz
15 = 15 Hz
16 = 20 Hz
Chxx.AlarmDisable BOOL Disables all alarms on the channel.
IMPORTANT: Consider the following:
When if you change this tag to 0, that is, so alarms are not disabled, you
must also enable the individual alarms for them to work.
For example, if you want to use the Low Low alarm for a channel, you
must set the Chxx.AlarmDisable to 0 and set the Chxx.LLAlarmEn output
tag to 1 so the alarm is enabled.
This applies to all alarms on the module.
Conversely, if you set this tag to 1, alarms are disabled regardless of the
setting on the alarm enable tag for any alarm.
0 = Alarms are not disabled
1 = Alarms are disabled (default)
Chxx.ProcessAlarmLatchEn BOOL Configures Process alarms to latch until they are explicitly unlatched.
The Process alarms include:
HighHigh alarm
High alarm
Low alarm
LowLow alarm
0 = Latching disabled (default)
1 = Latching enabled
Chxx.RateAlarmLatchEn BOOL Configures the Rate alarm to latch until it is explicitly unlatched. 0 = Latching disabled (default)
1 = Latching enabled
Chxx.OpenWireEn BOOL Enable the input Open Wire diagnostic 0 = Disabled (default)
1 = Enabled
Chxx.Disable BOOL Disables the channel.
When a channel is disabled, the following occurs:
The I/O status indicator for the channel turns off.
The Chxx.Fault input tag is set to 1.
0 = Channel is enabled (default)
1 = Channel is disabled
