Allen-Bradley 5069-IF8 User Manual

38 Rockwell Automation Publication 5000-UM005B-EN-P - November 2015
Chapter 3 Current/Voltage Analog Input Module Features (5069-IF8)
Module Features
The 5069-IF8 module has the following features:
•
Multiple Input Ranges
•
Notch Filter
•
Digital Filter
•
Underrange/Overrange Detection
•
Process Alarms
•
Rate Alarm
•
Sensor Offset
•
Open Wire Detection
•
Over Temperature Detection
Multiple Input Ranges
The 5069-IF8 module supports multiple input ranges. The input type that you
choose during module configuration determines the available input ranges. An
input type is chosen on a channel-by-channel basis.
To see where to choose an input range for the 5069-IF8 module, see
page 93.
Table 5 - Input Ranges
Input Type Available Input Range
Current (mA) • 0…20 mA
• 4…20 mA
Voltage (V) • -10…10V
• 0…5V
• 0…10V
