Page #53 background imageLoading...
Page #53 background image
Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 53
Current/Voltage/Temperature-sensing Analog Input Module Features (5069-IY4) Chapter 4
Multiple Input Ranges
The 5069-IY4 module offers multiple input ranges. The input type that you
choose during module configuration determines the available input ranges.
For the RTD input type, the sensor type that you choose determines the available
input ranges. The Logix Designer automatically sets the Input Range to the valid
setting after you select a sensor type.
Table 12 describes the available module input ranges.
To see where to choose an input range for the 5069-IY4 module, see
page 96.
Table 12 - 5069-IY4 Module - Channel Input Ranges
Input Type Sensor Type Available Input Ranges
Current (mA) N/A One of the following:
0…20 mA
4…20 mA
Voltage (V) N/A One of the following:
-10…10V
0…5V
0…10V
RTD Ohm One of the following:
1…500
2…1000
4…2000
8…4000
100 PT 385 1…500
200 PT 385 2…1000
500 PT 385 4…2000
1000 PT 385 8…4000
100 PT 3916 1…500
200 PT 3916 2…1000
500 PT 3916 4…2000
1000 PT 3916 8…4000
10 CU 427 1…500
120 NI 672 1…500
100 NI 618 1…500
120 NI 618 1…500
200 NI 618 2…1000
500 NI 618 4…2000
Thermocouple mV or any Thermocouple type -100…100 mV
