Chapter 5 Current/Voltage Analog Output Module Features (5069-OF4, 5069-OF8)
Module Features
The 5069 Compact I/O analog output modules have the following features:
•
Multiple Output Ranges
•
Channel Offset
•
Hold for Initialization
•
Connection Fault Handling
•
Output Clamping
•
Clamp Alarming
•
Output Ramping/Rate Limiting
•
No Load Detection
•
Short Circuit Protection
•
Over Temperature Detection
Multiple Output Ranges
The 5069 Compact I/O analog output modules offer multiple output ranges.
The output type that you choose during module configuration determines the
available ranges.
To see where to choose an output range, see the following:
• 5069-OF4 module -
page 101
• 5069-OF8 module, see
page 105
Table 21 - Output Ranges
Input Type Available Output Range
Current (mA) • 0…20 mA
• 4…20 mA
Voltage (V) • -10…10V
• 0…5V
• 0…10V
