88 Rockwell Automation Publication 5000-UM005B-EN-P - November 2015
Chapter 6 Configure the Module
Edit the Module
Configuration Common
Categories
You click the category names in the New Module dialog box to view and change
the configuration parameters that are associated with that module.
Some new module configuration categories apply to all 5069 Compact I/O
analog I/O modules. Some categories are specific to the module type.
The following categories apply to all 5069 Compact I/O analog I/O modules
and are described in this section:
•
General Category
•
Connection Category
•
Module Info Category
General Category
The General category appears first when you create a module. The parameters in
this category are the same for all analog I/O modules.
You use this category to complete the following tasks:
• Name the module.
• Assign a slot number.
• Describe the module.
• Access the Module Definition.
IMPORTANT
This chapter shows how to edit configuration when you add the module to the
Logix Designer application project.
If you access the module configuration after it has been added to the project,
the dialog box is named Module Properties. The Module Properties dialog box
shows the same categories as the New Module dialog box.
IMPORTANT
A slot number is a required.
