Page #77 background image
Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 77
Current/Voltage Analog Output Module Features (5069-OF4, 5069-OF8) Chapter 5
Final Fault State Value
The Final Fault State Value defines the value to which the output goes after the
Fault State Duration time expires.
Output State Once Connection is Re-established
Once the connection between the owner-controller and output module is re-
established, the output resumes normal operation.
To see where to set the Connection Fault Handling parameters, see the
following:
5069-OF4 module -
page 101
5069-OF8 module, see
page 105
Output Clamping
Output Clamping limits the output from the analog module to remain within a
range configured by the controller, even when the controller commands an
output outside that range.
Once clamp values are set, if data received from the controller exceeds those
clamps, the following events occur:
The output value transitions to the clamp limit but not to the requested
value.
The appropriate limit alarm is triggered.
For more information on limit alarms, see
Clamp Alarming on page 78.
For example, an application can set the high clamp on a module for 8V and the
low clamp for -8V. If a controller sends a value corresponding to 9V to the
module, the module applies only 8V to its screw terminals.
