A-4 Supplemental Drive Information
Electrical Voltage Tolerance: 200-240V ±10%
380-480V ±10%
Frequency Tolerance: 48-63 Hz
Input Phases: Three-phase input provides full rating. Single-phase
operation provides 50% rated current.
Displacement Power Factor: 0.98 across entire speed range
Efficiency: 97.5% at rated amps, nominal line voltage
Maximum Short Circuit Rating: 100,000 Amps Symmetrical (Frame C Drives)
200,000 Amps Symmetrical (Frame D, E, F Drives)
Actual Short Circuit Rating: Determined by AIC Rating of installed fuse/circuit
breaker
Transistor Type: Isolated Gate Bipolar (IGBT)
Internal DC Bus Choke:
200-240V AC Input:
380-480V AC Input:
11-37 kW (15-50 HP) Panel Mount Drives
11-110 kW (15-150 HP) Panel Mount Drives
Control Method: Sinusoidal PWM, Volts/Hertz
Carrier Frequency
Frames C and D:
Frames E and F:
2-10 kHz, Drive rating based on 4 kHz
2-8 kHz, Drive rating based on 4 kHz
Frequency Accuracy
Digital Input:
Analog Input:
Analog Output:
Within ±0.05% of set output frequency
Within 0.5% of maximum output frequency, 10-Bit
resolution
±2% of full scale, 10-Bit resolution
Speed Regulation - Open Loop with Slip
Compensation:
±1% of base speed across a 60:1 speed range
Output Frequency: 0-320 Hz (programmable)
Stop Modes: Multiple programmable stop modes including - Ramp,
Coast, DC-Brake, Ramp-to-Hold and S Curve.
Accel/Decel: Two independently programmable accel and decel
times. Each time may be programmed from 0 - 600
seconds in 0.1 second increments.
Intermittent Overload: 110% Overload capability for up to 1 minute
Electronic Motor Overload Protection Class 10 protection with speed sensitive response.
Control Inputs Digital: Quantity: (3) Semi-programmable
(4) Programmable
Ty p e
Source Mode (SRC):
Sink Mode (SNK):
18-24V = ON, 0-6V = OFF
0-6V = ON, 18-24V = OFF
Analog: Quantity: (1) Isolated, –10 to 10V or 4-20mA
(1) Non-isolated, 0 to 10V or 4-20mA
Specification
Resolution:
0 to 10V DC Analog:
4-20mA Analog:
External Pot:
10-bit
100k ohm input impedance
250 ohm input impedance
1-10k ohm, 2 Watt minimum
Category Specification
