Aritech 2X Series User Manual

Chapter 5: Technical specifications
2X Series Installation Manual 111
Typical expansion board current
consumption
Network board
DACT board
DACT board (with GPRS board)
Loop board [1]
Peripherals boards [1]
2010-2-PIB
2010-2-PIB-8I
2010-2-PIB-8O
2010-2-PIB-8I8O
Zone LED boards
20/24-zones
40-zones
50 mA at 24 VDC
45 mA at 24 VDC
100 mA at 24 VDC
120 mA at 24 VDC
26 mA at 24 VDC
25 mA at 24 VDC
16 mA at 24 VDC
26 mA at 24 VDC
12 mA at 24 VDC
14 mA at 24 VDC
Q
uiescent current (Imax a) 2.5 A max. at 24 VDC
A
larm current (Imax b) 4 A max. at 24 VDC
[1] No loads connected.
Battery and battery charger specifications
For recommended battery specifications, see “Battery maintenance” on page
107.
Type
Sealed lead-acid batteries (2X)
Battery charging voltage
27.3 V at 20ºC – 36 mV/ºC
Battery charging current
1.2 A max.
Low battery indication
23.6 VDC ± 1% at 25ºC
Note: Additional 0.2 V (max.) drop if Imax b current in battery
cables.
System shutdown warning
21.5 VDC ± 1% at 25ºC
System shutdown (for battery
protection)
21 VDC ± 1% at 25ºC
LCD specifications
Display type
240 x 128 dot graphic LCD (monochromatic)
LCD dimensions (L x W)
83 x 44 mm (active area)
Backligh
t type LED style
Backlight colour
White
