class Configures the installation loop wiring Class (Class A or Class B).
Autosetup
Select the Autosetup option to automatically configure installed loop devices.
Autosetup assigns a default configuration for each device type detected.
To begin autosetup:
1. Select Field setup from the Main menu, and then select Autosetup.
2. Select the corresponding loop or All loops.
During the search the LCD displays the message “Autosetup in progress”.
When the autosetup is complete the list of detected devices is displayed.
3. Press F4 (Enter), and then press F1 (Back).
4. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
Autosetup will:
• Assign all initiating devices (including zone modules) to zone 1
• Assign all sounder devices to the default sounder output group (output group
number 1)
• Assign all nonsupervised outputs (relays) to the default program output group
(output group number 301)
• Assign all extinguishing devices to the default extinguishing output group
(output group number 801)
Extinguishing output groups are only activated with a confirmed alarm. They
are not activated by zone alarms and rules.
• Assign all fire routing outputs (where available) to the default fire routing
output group (output group number 971)
• Assign all fire protection outputs (where available) to the default fire protection
output group (output group number 981)
• Assign the default initial zone to zone 1
By default all zones activate all output groups with no delay.
Note: Autosetup is incremental and retains the device text description for
previously configured devices.
