Chapter 1: Introduction
6 2X Series Installation Manual
Configuration options
Depending on your configuration, the labels for some interface buttons may
change. See Table 2 below.
Table 2: Configured changes to interface buttons and LEDs
Item
EN 54 NEN 2575
10
All Output Groups Start/Stop All Evacuation Start/Stop
11
Programmable output group start/stop Evacuation area sounders start/stop [1]
15
Sounder Start/Stop Fire Sounder Start/Stop
[1]
If the evacuation panel is operating in NEN 2575 mode, only sounder output groups can be
associated with the programmable start/stop buttons.
Front panel controls and indicators
Operational features described in this section are not available to all users. More
information on control panel operation and access restrictions can be found in
the topic “User levels” on page 36.
Common controls and indicators
The table below includes information for the common controls and indicators
available for fire, repeater, and evacuation panels.
Table 3: Common controls and indicators
Control/LED
LED colour Description
Supply LED
Green Indicates that the system is powered up.
General Test LED
Yellow Indicates that one or more features or devices are
being tested.
General Disable LED
Yellow Indicates that one or more features or devices are
disabled.
General Fault LED
Yellow Indicates a general fault. The fault LED for the
corresponding device or feature also flashes.
Alarm LED
Red Indicates a fire alarm.
A flashing LED indicates that the alarm was activated
by a detector. A steady LED indicates that the alarm
was activated by a manual call point.
Fire Routing
On
/Acknowledged
button and LED
Red Cancels a previously configured delay as it counts
down and activates fire routing.
A flashing LED indicates that fire routing has been
activated. A steady LED indicates that the fire routing
signal has been acknowledged by the remote
monitoring equipment.
