Relay Connector Maximum load
K03 3 X 31 15 A / 250 V AC
15 A / 30 V DC
RC* protected
K04 3 X 31 10 A / 250 V AC
10 A / 30 V DC
resistive load
K05 3 X 30 10 A / 250 V AC
10 A / 30 V DC
resistive load
K06 3 X 30 10 A / 250 V AC
10 A / 30 V DC
resistive load
K07 3 X 30 10 A / 250 V AC
10 A / 30 V DC
resistive load
K08 3 X 30 10 A / 250 V AC
10 A / 30 V DC
resistive load
K09 3 X 30 10 A / 250 V AC
10 A / 30 V DC
resistive load
K10 3 X 32 10 A / 250 V AC
10 A / 30 V DC
resistive load
K11 3 X 32 10 A / 250 V AC
10 A / 30 V DC
resistive load
K12 3 X 32 10 A / 250 V AC
10 A / 30 V DC
resistive load
K13 3 X 32 10 A / 250 V AC
10 A / 30 V DC
resistive load
K14 3 X 32 10 A / 250 V AC
10 A / 30 V DC
resistive load
K15 3 X 32 10 A / 250 V AC
10 A / 30 V DC
resistive load
* = Resistor Capacitor
6.4 Icons used
Status icons
Name Icon Description
Instruction book
116 2920 1815 04
