12.2 Settings of safety valves
Item Opening
pressure
Opening pressure
Low-pressure safety valve(s) for 7 up to 10.4 bar (101.5 up to
151 psi) compressors
3.7 bar(e) 54 psig
Low-pressure safety valve(s) for 13 bar (190 psi) compressors 4.5 bar(e) 65 psig
High-pressure safety valve(s) for 7 and 8.6 bar (101.5 and 125
psi) compressors
9.3 bar(e) 135 psig
High-pressure safety valve(s) for 10 and 10.4 bar (145 and
151 psi) compressors
11 bar(e) 160 psig
High-pressure safety valve(s) for 13 bar (190 psi) compressors 13.7 bar(e) 200 psig
12.3 Settings for overload relay
50 Hz compressors
ZT/ZR 110 compressors designed for a maximum inlet temperature of 40 ˚C/104 ˚F with IE2 motor
Supply voltage
(V)
Recommended overload setting F21
(A)
380 128.8
400 122.2
500 97.6
690 70.4
ZT/ZR 110 compressors designed for a maximum inlet temperature of 40 ˚C/104 ˚F with IE3 motor
Supply voltage
(V)
Recommended overload setting F21
(A)
380 129
400 123
500 98
690 71
ZT/ZR 110 compressors designed for a maximum inlet temperature of 50 ˚C/122 ˚F with IE2 motor
Supply voltage
(V)
Recommended overload setting F21
(A)
380 153.8
400 146.1
500 116.9
690 83.7
Instruction book
2920 1815 04 299
