Reference Name
4 Condensate valve, aftercooler
5 Warning: under tension
6 Read Instruction manual before starting the compressor
7 Switch off the voltage and depressurize the compressor before maintenance or repair
8 Before connecting the compressor electrically, consult the Instruction manual for the
motor rotation direction
9 Torques for steel (Fe) or brass (CuZn) bolts
10 Consult the Instruction manual before greasing
11 Switch off the voltage before removing the protecting cover inside the electric cabinet
12 Oil the gaskets, screw on the filters and tighten by hand (approx. one half turn)
13 Consult the Instruction manual before maintenance or repair
14 Cooling water outlet
15 Cooling water inlet
7.10 Pictographs, Elektronikon control system
Control panel of Elektronikon Controller
Reference Name
1 Start
2 Stop
3 Automatic operation
4 Alarm
5 Voltage on
6 Emergency stop
7 Key to go to next field on display
8 Keys to scroll through display
Instruction book
2920 1815 04 235
