3.10 Calling up menus
When the voltage is switched on, the Main screen is shown automatically.
Calling up menus
Starting from the Main screen:
• Either use the key ”Menu” (F1) to scroll to the first submenu “Status data” and press the key “Select”
(F2) to select this submenu.
• Or use the key “Menu” (F1) to scroll to the first submenu “Status data”, then use keys (1) to scroll to
another submenu and press the key ”Select” (F2) to select this submenu.
• Or use the key “Show More” (F2) for a quick look at the actual status of the compressor.
Returning to the Main screen or other menus
• Whenever displayed on the bottom line of a submenu, press the key “Menu” (F1) to return to a
previous menu.
• Whenever displayed, press the key “MainScreen” to return the Main screen.
3.11 Main screen menu
Control panel
Instruction book
2920 1815 04 53
