Unit
Min.
(Pack
version)
Min.
(Full-
Feature
version)
Max.
Max. (with
Energy
Recovery)
* 125 psi (60 Hz) 58.0 94.3 124.8 117.6
* 145 psi (50 Hz) 101.5 108.8 145.1 137.9
* 150.8 psi (60 Hz) 101.5 108.8 150.9 143.7
* 188.5 psi (50 Hz) 101.5 137.8 188.6 181.4
* 188.5 psi (60 Hz) 101.5 137.8 188.6 181.4
Control timers
s
Unload time 3 3 20 20
Minimum stop time 20 20 99 99
Y-D starter
s
Y-D time 10 10 30 30
Y-D time with motor voltage > or = 2.3 kV 0 0 30 30
Load delay 3 3 30 30
Load delay with motor voltage > or = 2.3 kV 13 13 30 30
Automatic Restart After Voltage Failure - ARAVF
s
Maximum power down time 20 20 3600 3600
Restart delay 0 0 255 255
Others
s
External communication timeout 10 10 60 60
6.19 Web server
All controllers have a built-in web server that allows direct connection to the company network or to a
dedicated PC via a local area network (LAN). This allows to consult certain data and settings via a PC
instead of the display of the controller.
Getting started
If the unit is equipped with a SMARTBOX, the network connection of the Elektronikon is
already in use. To allow the web server functionality, the network cable that is
connected to the SMARTBOX should be unplugged and replaced by the cable of the
company network.
If both the web server functionality and SMARTBOX are required, please contact your
local Atlas Copco Customer Center for support.
Make sure you are logged in as administrator.
• Use the internal network card from your computer or a USB to LAN adapter.
Instruction book
2920 1815 04 165
