10. Removal and installation of projector covers
Image 10-16
10.9 Installation of the top cover
Necessary tools
Allenkey3mm
How to install the top cover of the projector?
1. Place the top cover on the projector so that both holes matches the adjustment studs on to p of the projector.
Image 10-17
Mount top cover
2. Turn all 3 fixation screws. Insert the washer between the screw and the top co ver.
74 R5905050 DP2K C-SERIES 10/07/2012
