HDD models validated by Barco
Only the original HDD spare parts provided by Barco or models validated by Barco (see list below) can be
used in the ICMP(-X). All deviations from this rule void warranty.
HDD model ICMP-X ICMP
1TB: HGST – Western Digital (order code:
HCC541010A9E630 or
HCC541010B9E660)
Yes Yes
1TB: Western Digital black drives (order
code: WD10JQLX-22JFGT0)
Yes Yes
1TB: Seagate (order code :
ST1000NX0313)
Yes Yes
2TB: Seagate (order code :
ST2000NX0253)
Yes Yes
4TB: Seagate SSD (order code:
XA3840ME10063)
Yes Yes, only if the GEN1 storage controller is
replaced by a GEN2 storage controller. Software
version 1.4.2 or higher is needed.
7.3 What are the possible HDD swaps
General
There are several possible scenarios for replacing (exchange) hard drives on the ICMP(-X). The situation is
different depending on the device type (ICMP or ICMP-X) and whether to replace one or more disks.
Continuity of data present on the disks is also impacted depending on the type of exchange. Degraded
operation or RAID initialization may be required.
List of available actions
The following table exposes all possible swaps available concerning HDDs on ICMP(-X):
Replacing drives should always be done while the power is off.
Type of HDD swap
On ICMP On ICMP-X
1 HDD replaced.
• Content is preserved.
• ICMP automatically starts rebuild.
• Process takes about 3-4 hours
for 1TB HDD and could takes
about 13-14 hours for 4TB HDD.
• Content is preserved.
• ICMP-X automatically starts
rebuild.
• Process takes about 3-4 hours
for 1TB HDD and could takes
about 13-14 hours for 4TB HDD.
3 HDDs replaced separately
(previous kit of one disk used
three times).
• All content will be lost.
• RAID initialization need to be
perform with Communicator.
• immediately usable after RAID
initialization + restart (content
can be ingested).
• All content will be lost.
• RAID initialization need to be
perform with Web Communicator.
• immediately usable after RAID
initialization + restart (content
can be ingested).
Barco HDD replacement kit
(Spare part kit provided by
Barco with a set of 3 hard
disks configured to GEN1
storage controller).
• RAID initialization does not need
to be performed.
• Content can be ingested
immediately.
• RAID initialization needs to be
perform with Web Communicator.
• immediately usable after RAID
initialization + restart (content
can be ingested).
ICMP(-X)

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
