Barco DP2K-23B User Manual

91R5905753 /17 DPxK-19B/23B/P
General settings Advanced settings
Source Port Port type Mode Scan type Color
space
Pixel mapping Calibration
Progressive SF -
2nd field
dominant
YCbCr 3G - Level A -
Quad Link
Single
3G - Level B -
Quad Link
4:4:4 10
bits/color
Progressive RGB 3G - Level A -
Quad Link
Single
3G - Level B -
Quad Link
Progressive SF -
1st field dominant
RGB 3G - Level A -
Quad Link
Single
3G - Level B -
Quad Link
Progressive SF -
1st field dominant
RGB 3G - Level A -
Quad Link
Single
3G - Level B -
Quad Link
4:4:4 12
bits/color
Progressive XYZ/
RGB
3G - Level A -
Quad Link
Single
3G - Level B -
Quad Link
Progressive SF -
1st field dominant
XYZ/
RGB
3G - Level A -
Quad Link
Single
3G - Level B -
Quad Link
Progressive SF -
2nd field
dominant
XYZ/
RGB
3G - Level A -
Quad Link
Single
3G - Level B -
Quad Link
HD-SDI - 4K 4:2:2 10
bits/color
Progressive YCbCr HD-SDI - Quad
Link
Single
Progressive SF -
1st field dominant
YCbCr HD-SDI - Quad
Link
Single
Progressive SF -
2nd field
dominant
YCbCr HD-SDI - Quad
Link
Single
6.8 Integrated Media Block/Server (optional)
Not available for purchase at Barco for use in Taiwanese market.
Depending on the projector configuration the projector card cage is either equipped with an ICP(-D)
or ICMP(-X). In case an ICP(-D) is installed then an IMB, IMS, or HDSDI input module can be
optionally inserted into the slot below the ICP(-D). This is not the case if the ICMP(-X) is installed.
For more information about the ICMP(-X) see chapter called ICMP(-X).
Input & communication

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
