R5905753 /17 DPxK-19B/23B/P42
Supported lamp types and their respective anode/cathode adapters for the S/M Lamp
House:
Lamp type
Supplier
Cathode adapter
S/M Lamp House
Barco Order No.
4kW DHP OSRAM XBO R865555K R9855937
3kW DHP OSRAM XBO R865555K R9855938
2kW DHP OSRAM XBO R865555K R9855956
1200W DHP OSRAM XBO R865555K R9855959
DXL40BAF USHIO R865555K R9855939
DXL30BAF USHIO R865555K R9855940
DXL20BAF USHIO R865555K R9855955
DXL12BAF USHIO R865555K R9855961
XDC-4000B PHILIPS R865555K R9856370
WARNING: Always use the correct Cathode adapter for the xenon lamp in the Lamp House.
Neglecting this may result in poor performance of the lamp and damage to the xenon lamp and
Lamp House. Some adapters looks the same, therefore check the engraved item number upon the
adapter to ensure you use the right adapter.
4.3 Removal of the Lamp House
WARNING: This procedure may only be performed by qualified technical service personnel.
WARNING: The Lamp House is very hot after operation. To avoid burns, let the projector cool down
for at least 15 minutes before proceeding to remove the Lamp House.
CAUTION: Due to its high internal pressure, the lamp may explode in either hot or cold states if
improperly handled.
Required tools
10mm nut driver or flat screw driver.
How to remove the Lamp House from the projector?
1. Make sure the projector is switched off and cooled down.
2. Remove the cover of the Lamp House compartment.
3. Release the two retaining screws (reference 1 Image 4–5) at the base of the Lamp House. Use a 10mm
nut driver or a flat screw driver.
4. Remove the Lamp House as follows:
1. Grip the Lamp House by the bottom handle and partially slide it out of the lamp compartment
2. Grip the Lamp House by both handles and remove it completely from the projector.
3. Place the Lamp House on a stable support.
Caution: Be aware of the weight of the lamp assembly. Take the necessary precautions to avoid
personal injury.
