Barco DP2K-23B User Manual

R5905753 /17 DPxK-19B/23B/P80
LED diagnostic
State description Normal operation
Error state
Software state (LED reference 2) flashing green red or orange
Operating System state (LED reference 3) green off, red or yellow
FMT FPGA state (LED reference 4) green red : unable to configure the FPGA
yellow : FPGA is loaded with the Boot
application
ICP FPGA state (LED reference 5) green red : unable to configure the FPGA
yellow : FPGA is loaded with the Boot
application
ICP functions:
• Stores all projector files. When board is replaced; clone package must be reloaded.
• Stores and generates test patterns.
• Scaling to native resolution, re-sizing, masking, line-insertion de-interlacing, subtitle overlay, color space
conversion, de-gamma, color correction
• Source Selection between alternative content and cinema content.
• Stores a Certificate and Private Key needed for Playback validation
• Contains a real time clock, which must be synchronized with the GMT/UTC time stored in the link decryptor
module or Integrated Media Block (see Communicator software)
• Handles unpacking of special video formats
The ICP board spare part kit is not default programmed for a projector. When using this board in a
projector the software must be re-installed after installation of the board.
When installing a new ICP board in a projector the Spatial Color Calibration file must be reloaded
and activated.
CAUTION: Make sure not to short circuit the battery on the board. That will destroy the board
completely !
6.4 Integrated Cinema Processor - Direct (ICP-D)
About ICP-D
The ICP-D (Integrated Cinema Processor - Direct) is a removable electronic assembly situated in the Card
Cage of the projector. The ICP-D process and formats DCI cinema content played from a Media Block and
delivers it to the projector (DMDs).
In case the projector is equipped with a Barco ICMP(-X) no ICP-D board is inserted. All ICP-D
functionality is integrated in the Barco ICMP(-X).
Whatever the projector type, ICP-D is always located above IMB.
A dedicated installation manual for ICP-D is available on the Barco’s partner zone.
An ICP-D can always replace an ICP in the field. Consult the dedicated installation manual for ICP-
D available on Barco’s partner zone.
Input & communication

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
