Barco DP2K-23B User Manual

127R5905753 /17 DPxK-19B/23B/P
HDMI 1.4 Supported Audio Formats
Format
Sample Rate Sample coding Bit depth
2 channels 32
44
48
88
96
L-PCM 16
5.1 channels 24 L-PCM 48
7.1 channels 20 L-PCM 48
7.18 ICMP(-X) reset
This procedure requires that ICMP(-X) version 1.2.4 or later is installed.
ICMP(-X) reset possibilities
• The Star button on the local keypad (Not for C- and B-series)
• The ICMP(-X) reset button ( labeled Reboot ICMP) in the GUI of the Communicator.
• The ICMP(-X) reset button ( labeled media server) in the GUI of the Communicator.
• The ICMP(-X) reset button ( labeled Reboot media server) in the GUI of the Commander.
• The ICMP(-X) reset button ( labeled Reboot media server) in the GUI of the Web Commander.
• The ICMP(-X) hardware reset button located on the front panel of the ICMP(-X) (Not recommended, use
only when all other reset possibilities are exhausted!)
How to reset the ICMP(-X)?
1. Click on the Control/ICMP/Reboot media server in the GUI of the Web Commander
or
Click on Control/ICMP/Reboot media server in the GUI of the Commander
Note: The behavior could be different depending the projector type. Please, refer to the
projector manual to obtain more details.
or
click on Maintenance/Reboot action/media server in the GUI of the Communicator (recommended)
or
click on Contol/projector/power/Reboot ICMP in the GUI of the Communicator (recommended)
or
press the Star button on the local keypad for a few seconds (Not for C- and B-series)
As a result the projector is safely prepared for the ICMP reboot. All ongoing events on the ICMP (e.g.
ingest) are requested to end. After a few seconds the ICMP is requested to restart. The READY LED on
the front panel of the ICMP starts to blink orange.
In case the ICMP(-X) is installed in DP4K-L series projector the lasers are switched off and the projector
remains in the same mode (e.g. Conditioned). The Star button on the local keypad starts blinking green.
After the reset of the ICMP(-X) the lasers are switched on again.
Once the READY LED lit continuous green the ICMP(-X) is up and running.
2. Did the reset of the ICMP(-X) fail?
► If yes, perform a hardware reset as follows:
1. switch off the lasers of the projector or switch of the projector lamp.
2. press the ICMP(-X) hardware reset button a few seconds (reference 3 Image 7–22) .
ICMP(-X)

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
