Barco DP2K-23B User Manual

153R5905753 /17 DPxK-19B/23B/P
Image 11–2 Up indication
2. Push the filter completely in.
3. Reinstall the input cover.
11.2 Remove and clean both bottom dust filters
How to remove
1. Remove the side cover.
2. Slide out the bottom front dust filter.
Image 11–3 Bottom front dust filter
3. Slide out the bottom back dust filter.
Image 11–4 Bottom back dust filter
Clean the dust filter
1. Remove most contamination with a vacuum cleaner in an other room or outside.
Maintenance

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
