Barco DP2K-23B User Manual

R5905753 /17 DPxK-19B/23B/P124
HDMI 2.0 Supported Dual (Twin) Link Formats (2D formats only)
Format Frame Rate
Color coding Bit depth
1920x1080
2048x1080
23.976
24
25
29.97
30
50
59.94
60
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
3840x2160
4096x2160
23.976
24
25
29.97
30
50
59.94
60
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
Both HDMI2 inputs (port A & port B) should have to same Format, Frame Rate and Color coding.
Port A should contain the 8 most significant bits of the pixel data, where port B should contain the 8
least significant bits of the pixel data. The pixel data will be reconstructed using the all 8 bits of port
A and using the 4 most significant bits of port B.
HDMI 2.0 Supported Passive 3D Formats (3D formats only)
Format Frame Rate
Color coding Bit depth
1920x1080
2048x1080
24
30
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
10
12
1920x1080
2048x1080
60 RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
3840x2160
4096x2160
24
30
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
In Passive 3D HDMI2 input port A should contain the pixel data of Left Eye and HDMI2 input port B
should contain the pixel data for Right Eye.
7.17 ICMP HDMI 1.4 specifications
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring
uncompressed video data and compressed/uncompressed digital audio data from a HDMI-
compliant device ("the source device") to a compatible computer monitor, video projector, digital
television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
ICMP(-X)

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
